Product
Large-format Schüco ASE sliding systems support panels up to several metres wide, opening interiors to terraces and gardens with minimal sightlines.
SLIDING & BIFOLD DOORS
Sliding and bifold aluminium door systems combine elegant design, expansive glazing and outstanding thermal performance for modern residential and commercial projects across Europe. Large glass panels maximise natural light while creating a seamless connection between indoor and outdoor spaces.
Designed for contemporary architecture and renovation projects alike, SmartEco sliding and bifold door solutions offer smooth operation, slim sightlines and excellent weather resistance. Precision-engineered aluminium profiles provide durability, security and long-term reliability.
Whether creating panoramic openings for private homes, terraces and garden rooms, or large-scale commercial entrances, our certified aluminium systems deliver comfort, energy efficiency and architectural freedom.
PRODUCT SYSTEMS
Schüco · Sliding & Bifold Doors
High-insulation lift-slide system
Thermal Insulation
Uw from 0.8 W/m²K
Air-Water-Wind
4 / 9A / C3
System Dimensions
Interlock 25 mm
Depth 174 mm
Acoustics
Rw up to 45 dB
System limitation
Max. Vent Height 3200 mm
Max. Weight 400 kg
Schüco · Sliding & Bifold Doors
Compact sliding system for residential projects
Thermal Insulation
Uw from 1.6 W/m²K
Air-Water-Wind
4 / 8A / C2
System Dimensions
Interlock 30 mm
Depth 155 mm
Acoustics
Rw up to 40 dB
System limitation
Max. Vent Height 2700 mm
Max. Weight 300 kg
Reynaers · Sliding & Bifold Doors
The infinite view
Thermal Insulation
Uw = 0.8 W/m²K
Air-Water-Wind
High
4 / E750 / C5
System Dimensions
Max Height Vent 4000 mm
Max Width Vent 3500 mm
Acoustics
Extreme
Rw(C;Ctr) = 46 (-1;-3) dB
System limitation
Vent = 750 kg
Fixed = 1200 kg
GALLERY
